Parameter
Potential Technology

Total Mercury (Hg)

Online Mercury Analyzer (Cold Vapor Atomic Fluorescence)

Breakthrough Detection

High-Sensitivity Mercury Analyzer

Mercury Trend

Continuous Mercury Monitoring

Moisture

Trace Moisture Analyzer

H₂S

TDLAS H₂S Analyzer

Description

The Mercury Removal Unit (MRU) is a critical gas conditioning process used to remove trace elemental and organic mercury (Hg) from natural gas streams. Mercury, even at extremely low concentrations, can cause severe corrosion and amalgamation damage to aluminum heat exchangers used in cryogenic units such as LNG and NGL recovery plants. In a typical MRU, natural gas passes through fixed-bed vessels filled with adsorbent media such as sulfur-impregnated activated carbon or molecular sieves, where mercury is captured. Dual-vessel configurations allow continuous operation during adsorbent replacement. Effective mercury removal ensures equipment protection, enhances plant reliability, and ensures compliance with downstream process and safety requirements.
